MODULES ANALYSETTE 22




FURTHER PARTICLE SIZERS




Module A-22 - Small Volume

Wet Dispersion Unit SVA

Order No.
22.8800.00
Accessories

Measuring Unit ANALYSETTE 22 NanoTec - in order to use the FRITSCH Small Volume Wet Dispersion Unit SVA you will need the ANALYSETTE 22 NanoTec Measuring Unit (Order No. 22.8000.00).
Detailed information about the Measuring Unit ANALYSETTE 22

For representative sample division - the foundation of any precise analysis - we recommend the
Rotary Cone Sample Divider LABORETTE 27

Conversion kit Extended for extreme chemical resistance

If you are working with extremely aggressive chemical dispersion liquids, like for example acetone or dimethylketone, you can order the SVA dispersion unit with the conversion kit for extreme chemical resistance.

Select Conversion kit

Conversion kit Extended for extreme chemical resistance

conversion kit Extended for extreme chemical resistance for small volume wet dispersion unit SVA
No. 22.8855.00

Conversion kit Extended for extreme chemical resistance for small volume wet dispersion unit SVA - 22.8800.00.
Consists of seals, O-rings and flow plate made of FFKM Kalrez® – the hoses are made of Santoprene®.
If you are working with extremely aggressive chemical dispersion liquids, like for example acetone or dimethylketone, you can order the SVA dispersion unit with this conversion kit for extreme chemical resistance.
If you already have a unit, you can order the conversion kit separately and your equipment can be retrofitted.


You can download a list of chemicals for the different dispersion units here:
List of suitable chemicals


Reference materials and certificates

Reference materials for regular inspection of the Laser Particle Sizer ANALYSETTE 22 NanoTec to ensure proper function. The reference materials offered by FRITSCH are delivered along with precise dispersion and measurement instructions and are accompanied by a certificate that states the upper and lower limits of the expected particle sizes. These limit values were determined using an internationally recognised process (NIST-traceable).

SELECT REFERENCE MATERIAL

Certified reference materials (NIST-traceable) for performance verification according to ISO 13320

test powder for wet dispersion, 10 - 100 µm
No. 85.2220.00
Test powder for wet dispersion, 10 - 100 <span class="to-lower">µm</span>

Test powder for wet dispersion, 10 - 100 µm (Box with 10 single-shots 0.5 g), certified reference material for performance verification of the FRITSCH Laser Particle Sizer ANALYSETTE 22 NanoTec, which is used for wet dispersion and for calibration according to ISO 13320 in regard to repeatability and reproducibility.
The test powder for wet dispersion is delivered in a box with 10 single-shots 0.5 g.
Also test suspensions for the inspection of the measurement precision as well as a test powder for dry dispersion are offered.


test suspension nano (approx. 200 nm) for system check
No. 85.2240.00
Test suspension nano (approx. 200 <span class="to-lower">nm</span>) for system check

Test suspension nano (approx. 200 nm) for system check (box with 10 single-shots 5 ml) for the inspection of the measurement precision of the FRITSCH Laser Particle Sizer ANALYSETTE 22 NanoTec, which is used for wet dispersion.
The test suspension nano for system check for wet dispersion is delivered in a box with 10 single-shots 5 ml.
Additional test suspensions for inspection of the measurement precision, as well as test powders for the calibration of the Laser Particle Sizer ANALYSETTE 22 NanoTec according to ISO 13320 in regard to repeatability and reproducibility are also offered.


test suspension 1 µm for system check
No. 85.2250.00
Test suspension 1 <span class="to-lower">µm</span> for system check

Test suspension 1 µm for system check (Box with 10 single-shots 5 ml) for inspection of the measurement precision of the FRITSCH Laser Particle Sizer ANALYSETTE 22 NanoTec, which is used for wet dispersion.
The test suspension 1 µm for system check for wet dispersion is delivered in a box with 10 single-shots 5 ml.
Additional test suspensions for inspection of the measurement precision as well as test powders for the calibration of the Laser Particle Sizer ANALYETTE 22 NanoTec according to ISO 13320 in regard to repeatability and reproducibility are also offered.


test suspension 10 µm for system check
No. 85.2260.00
Test suspension 10 <span class="to-lower">µm</span> for system check

Test suspension 10 µm for system check (Box with 10 single-shots 5 ml) for inspection of the measurement precision of the FRITSCH Laser Particle Sizer ANALYSETTE 22 NanoTec, which is used for wet dispersion.
The test suspension 10 µm for system check for wet dispersion is delivered in a box with 10 single-shots 5 ml.
Additional test suspensions for inspection of the measurement precision, as well as test powders for the calibration of the Laser Particle Sizer ANALYSETTE 22 NanoTec according to ISO 13320 in regard to repeatability and reproducibility are also offered.


FRITSCH reference materials according to ISO 13320

FRITSCH-test powder F-500, 0.5 - 50 µm, for wet and dry dispersion
No. 85.2100.00
FRITSCH-test powder F-500, 0.5 - 50 <span class="to-lower">µm</span>, for wet and dry dispersion

For calibration of the Laser Particle Sizer ANALYSETTE 22 NanoTec for wet and dry dispersion within the framework of a test equipment monitoring system as per ISO 13320.
The cost-efficient alternative (non-certified reference materials) for regular inspection of your Laser Particle Sizer ANALYSETTE 22.
The FRITSCH-test powder F-500, 0.5 - 50 µm is delivered in a handy 50 g bottle.


Certification

set of IQ/OQ blank forms
No. 96.1000.00
Set of IQ/OQ blank forms

Set of IQ/OQ blank forms, (questionnaire format – standards and implementation not included).
For the support of the initial operation resp. examination of the function of the FRITSCH Laser Particle Sizer according to ISO 13320, FRITSCH offers appropriate questionnaires as blank forms. Certificates for tests according to ISO 13320 available on request:


Certificates for tests according to ISO 13320 for ANALYSETTE 22 NanoTec
We offer the Performance Verification for the wet and dry dispersion. The verification must be carried out directly on the instrument either here in Idar-Oberstein or at your site. Therefore, we would like to provide you with an individual offer – according to your needs.
Performance Verification for wet dispersion – Order No. 96.0080.00
Performance Verification for dry dispersion – Order No. 96.0081.00


Just contact:
Mr. Stefan Fröhlich,
phone: 0049 67 84 70 150
froehlich@fritsch.de


Spare parts for small volume wet dispersion unit SVA

Spare parts for the small volume wet dispersion unit like cartridge, flow measuring cell, measuring cell glasses, seal sets.

SELECT SPARE PART

Spare parts for small volume wet dispersion unit SVA

Cartridge with cpl. flow measuring cell
No. 22.8590.04

Cartridge with cpl. flow measuring cell for insertion into the:
small volume wet dispersion unit SVA - article no. 22.8800.00
small volume wet dispersion unit SVM - article no. 22.8599.00


flow measuring cell cpl.
No. 22.8560.04
Flow measuring cell cpl. for wet dispersion unit

Replacement flow measuring cell inclusive measuring cell glass 4 mm and 12 mm cpl. for inserting into the flow measuring cell of the


wet dispersion unit - article no. 22.8500.00
small volume wet dispersion unit SVA - article no. 22.8800.00
small volume wet dispersion unit SVM - article no. 22.8599.00


measuring cell glass 4 mm for flow measuring cell
No. 22.8566.26
Measuring cell glass 4 mm for flow measuring cell for all wet dispersion units

Replacement measuring cell glass 4 mm for inserting into the
flow measuring cell article no. 22.8560.04 (ANALYSETTE 22)
flow measuring cell article no. 28.2510.00 (ANALYSETTE 28)


measuring cell glass cpl. 12 mm for flow measuring cell
No. 22.8561.04
Measuring cell glass cpl. 12 mm for flow measuring cell for all wet dispersion units

Replacement measuring cell glass 12 mm for inserting into the following flow measuring cell article no. 22.8560.04 of the
wet dispersion unit - article no. 22.8500.00
small volume wet dispersion unit SVA - article no. 22.8800.00
small volume wet dispersion unit SVM - article no. 22.8599.00


seal set Standard for flow measuring cell
No. 22.8851.15

The seal set Standard for flow measuring cell consists of O-rings and flow plate made of Viton® Extreme and can be utilized for the flow measuring cell article no. 22.8560.04 of the
wet dispersion unit - article no. 22.8500.00
small volume wet dispersion unit SVA - article no. 22.8800.00
small volume wet dispersion unit SVM - article no. 22.8599.00


seal set Extended for extreme chemical resistance for flow measuring cells
No. 22.8856.16
Seal set Extended for extreme chemical resistance for flow measuring cells

The seal set Extended for extreme chemical resistance consists of O-rings and flow plate made of FFKM Kalrez® and can be utilized for the following flow measuring cell article no. 22.850.04 of the
wet dispersion unit - article no. 22.8500.00
small volume wet dispersion unit SVA - article no. 22.8800.00
small volume wet dispersion unit SVM - article no. 22.8599.00


Order No.
22.8800.00
Sales Consultant Particle Sizing
M.Sc. (Phys.) Maik Paluga
FRITSCH GmbH - Milling and Sizing
Industriestrasse 8
55743 Idar-Oberstein
Phone +49 67 84 70 188
Mobile +49 151 40 48 38 41
