Laser Particle Sizer ANALYSETTE 22 NanoTec - Reliable measurement down into the nano range

The ANALYSETTE 22 NanoTec with a measuring range of 0.01 - 2100 µm is the ideal Laser Particle Sizer for particle size analysis – in production and quality control as well as in research and development. Your advantages: extremely simple operation, short analysis times and reliable reproducible results. And a convincing combination of price and performance.

Modular design – maximum flexibility

The ANALYSETTE 22 NanoTec consists of a compact measuring unit that can be quickly and easily combined with different dispersion units for dry or wet measurement. Due to the practical modular system all dispersion modules of the ANALYSETTE 22 NanoTec can be connected to the measuring unit individually or in combination. And to change dispersion, the measuring cell is simply switched.
Our tip: Wet dispersion is the ideal dispersion method for most samples. For easily soluble samples or samples that swell significantly, dry dispersion or the falling chute is the right solution.

Choose the measuring unit and the right dispersion module for your measurement task

7 results
Details ANALYSETTE 22
NanoTec
  • Method of analysis
  • Static Light Scattering
  • Measuring range
  • 0.01 - 2100 µm
  • Sample carrier medium
  • Suspension/sample volume
Details Wet Dispersion Unit
  • Method of analysis
  • Static Light Scattering
  • Measuring range
  • 0.01 - 2100 µm
  • Sample carrier medium
  • water
  • Suspension/sample volume
  • 300 - 500 ml
Details AutoSampler
  • Method of analysis
  • Static Light Scattering
  • Measuring range
  • 0.01 - 2100 µm
  • Sample carrier medium
  • water
  • Suspension/sample volume
  • up to 26 containers at 40 ml
Details Wet Dispersion Unit SVA
  • Method of analysis
  • Static Light Scattering
  • Measuring range
  • 0.01 - 600 µm
  • Sample carrier medium
  • almost all dispersion liquids
  • Suspension/sample volume
  • 50 ml
Details Wet Dispersion Unit SVM
  • Method of analysis
  • Static Light Scattering
  • Measuring range
  • 0.01 - 600 µm
  • Sample carrier medium
  • water, organic solvents
  • Suspension/sample volume
  • 100 ml
Details Dry Dispersion Unit
  • Method of analysis
  • Static Light Scattering
  • Measuring range
  • 0.1 - 2100 µm
  • Sample carrier medium
  • air
  • Suspension/sample volume
  • 1 - 100 ml
Details Falling Chute
  • Method of analysis
  • Static Light Scattering
  • Measuring range
  • 0.1 - 2100 µm
  • Sample carrier medium
  • without dispersion and compressed air
  • Suspension/sample volume
  • 1 - 100 ml

Downloads

Product leaflet
Laser Particle Sizer
ANALYSETTE 22 NanoTec
